●Technical parameters
HYDAC 0400DN025W/HC technical parameters:
Working medium: general hydraulic oil, phosphate ester hydraulic oil, lubricating oil, etc.
Filtration accuracy: 1-100 microns
Working pressure: 1.6MPa
Working temperature: -4℃～100℃
●Performance characteristics
HYDAC 0400DN025W/HC test standard
Filter element-rupture resistance verification according to ISO 2941
Filter element-structural integrity according to ISO 2942
Filter element-material and liquid compatibility verification according to ISO 2943
Filter element-end load test method according to ISO 3723
Filter element-determination of fatigue characteristics according to ISO 3724
Filter element-pressure difference flow characteristics according to ISO 3968
Filter element—Multi-pass method for determining filter characteristics according to ISO 4572
●Application field
HYDAC 0400DN025W/HC application field:
Electronics and pharmaceuticals: used for the pretreatment and filtration of reverse osmosis water and deionized water, and the pretreatment of washing liquid and glucose.
Textile and packaging: The filter element is used for the purification and uniform filtration of polyester melt in the drawing process, the protection and filtration of the air compressor, and the degreasing and water removal of the compressor.
Thermal power and nuclear power: the lubrication system of steam turbines and boilers, the purification of speed control systems, fans and dust removal systems.
Mechanical processing equipment: lubrication systems and compressed air purification of papermaking machinery, mining machinery, injection molding machines and large precision machinery, dust recovery and filtration of spraying equipment.
