Replacement PALL return line filter element HC9020

Whatsapp Me

【HC9020FKS8Z】——Pall filter element HC9020 series PALl filter element

1. Brief introduction of pall filter element HC9020 series

   【HC9020FKS8Z】——Pall filter element HC9020 series is the product of Xinxiang Haite Filter Co., Ltd. instead of the original American PAL filter element. 【HC9020FKS8Z】——Pall filter element HC9020 series is mainly used for the filtration of oil in the hydraulic system. It is used to filter out particulate impurities and rubber impurities in the hydraulic system to ensure the cleanliness of the system.

2.【HC9020FKS8Z】——Pall filter element HC9020 series

   1. HC9020FKS8Z Pall filter element performance index:

The filtering precision is 1～25μm (special precision can be customized)

Filter material: glass fiber, wood pulp paper, metal mesh, etc. (different filter materials are selected according to the different precision requirements)

Normal working pressure (MAX): 0.6~32Mpa

Working medium: general hydraulic oil, phosphate ester hydraulic oil, emulsion, water-glycol

Working temperature: -30℃ ～ +110℃

   2. HC9020FKS8Z —— Pall filter element application field

Metallurgy:【HC9020FKS8Z】——Pall filter element HC9020 series is used for the filtration of the hydraulic system of the rolling mill and the continuous casting machine and the filtration of various lubricating equipment

Petrochemical:【HC9020FKS8Z】——Pall filter element HC9020 series is used for separation and recovery of products in the process of oil refining and chemical production, liquid purification, purification of magnetic tape, CD and photographic film in the manufacturing process, and oil field injection well water And natural gas dust particle filtration.

Textile and packaging: [HC9020FKS8Z]-Pall (pall) filter element HC9020 series are used for the purification and uniform filtration of polyester melt in the drawing process, the protection and filtration of air compressors, and the degreasing and dewatering of compressed gas.

Electronics and pharmaceuticals: [HC9020FKS8Z]-Pall (pall) filter element HC9020 series is used for pretreatment filtration of reverse osmosis water, deionized water, washing liquid and glucose pretreatment filtration.

Thermal power and nuclear power: [HC9020FKS8Z]-Pall (pall) filter element HC9020 series is used for the purification of steam turbines, boiler lubrication systems, speed control systems, bypass control systems, feed water pumps, fans and dust removal systems.

Mechanical processing equipment: 【HC9020FKS8Z】——Pall filter element HC9020 series is used for lubrication system and compressed air purification of papermaking machinery, mining machinery, injection molding machine and large precision machinery, dust recovery and filtration of tobacco processing equipment and spraying equipment .

Industrial oils: such as hydraulic oil, transformer oil, turbine oil, refrigerating oil, lubricating oil, anti-fuel oil, etc.



3. Pall filter element HC9020 series model

HC9020FKZ4H                     HC9020FKP4H                         HC9020FKN4H                    HC9020FKS4H

HC9020FKT4H                     HC9020FKZ8H                          HC9020FKP8H                   HC9020FKN8H

HC9020FKS8H                     HC9020FKT8H                         HC9020FKZ4Z                    HC9020FKP4Z

HC9020FKN4Z                     HC9020FKS4Z                         HC9020FKT4Z                    HC9020FKZ8Z

HC9020FKP8Z                     HC9020FKN8Z                        HC9020FKS8Z                      HC9020FKT8Z

HC9020FDP4H                    HC9020FDN4H                        HC9020FDS4H                      HC9020FDT4H

HC9020FDP8H                   HC9020FDN8H                       HC9020FDS8H                       HC9020FDT8H

HC9020FDP4Z                    HC9020FDN4Z                        HC9020FDS4Z                       HC9020FDT4Z

HC9020FDP8Z                    HC9020FDN8Z                       HC9020FDS8Z                       HC9020FDT8Z

HC9020FUP4H                    HC9020FUN4H                      HC9020FUS4H                         HC9020FUT4H

HC9020FUP8H                   HC9020FUN8H                       HC9020FUS8H                        HC9020FUT8H

HC9020FUP4Z                   HC9020FUN4Z                         HC9020FUS4Z                        HC9020FUT4Z

HC9020FUP8Z                 HC9020FUN8Z                         HC9020FUS8Z                         HC9020FUT8Z

Four, Pall filter model description

HC9020FKS8Z pall filter element

(1) Serial number: HC9020 series—HC9020FKS8Z

(2) Pressure: H-32MPa M-16MPa C-3.0MPa L-1.6MPa

(3) Accuracy: Z-1μm P-3μm N-6μm S-10μm T-25μm

(4) Material: wave fiber filter paper-BN stainless steel woven mesh-W wood pulp filter paper-P stainless steel sintered mesh-V

(5) Sealing material: H-fluorine rubber ring Z-nitrile rubber

5. Recommendations for other related models:
HC9020FDP8H HC9020FDP8Z HC9020FDT8Z HC9020FUN4Z
